產(chǎn)品中心

/ 24W Economic Type

24W Economic Type

?? ?Worldwide Scope AC/DC Input
?? ?Regulated output, Low ripple noise
?? ?Small size: 39.5*25.5*22mm
?? ?Protection type: Overload protection / Short circuit protection / Over temperature protection
?? ?Flexible peripheral circuit design, PCB soldering method
?? ?Aluminum shell, Natural cooling
?? ?CE/RoHS certified

Compared with 24W high performance type, There is no EMC circuit, Lightning protection and surge circuit, Pulse group attenuation circuit, Output common mode differential mode filter and output filter capacitor.

??Click on the ACDC power?module below to learn more

系列標(biāo)題 功率(W) 輸入電壓(VAC/DC) 輸出電壓
(VDC)
輸出電路 隔離耐壓(VAC) 封裝形狀 封裝尺寸
(mm)
PDF
HE05P15LRN 15 85~265VAC/100~370VDC 5 Single output 3000 DIP 39.5*25.5*22
HE06P15LRN 15 85~265VAC/100~370VDC 6 Single output 3000 DIP 39.5*25.5*22
HE09P24LRN 24 85~265VAC/100~370VDC 9 Single output 3000 DIP 39.5*25.5*22
HE12P24LRN 24 85~265VAC/100~370VDC 12 Single output 3000 DIP 39.5*25.5*22
HE15P24LRN 24 85~265VAC/100~370VDC 15 Single output 3000 DIP 39.5*25.5*22
HE20P24LRN 24 85~265VAC/100~370VDC 20 Single output 3000 DIP 39.5*25.5*22
HE24P24LRN 24 85~265VAC/100~370VDC 24 Single output 3000 DIP 39.5*25.5*22
HE28P24LRN 24 85~265VAC/100~370VDC 28 Single output 3000 DIP 39.5*25.5*22
HE36P24LRN 24 85~265VAC/100~370VDC 36 Single output 3000 DIP 39.5*25.5*22
